China flat pack container houses containerized container homes is based on the single container house as the the basic unit, the single unit is built through special section steel welding and bolt connection, the different units are connected by bolts.
Item No :
C-027Order(MOQ) :
1 setPayment :
50% deposite,50% before shipmentProduct Origin :
Guangdong provinceColor :
customizedShipping Port :
Nansha portLead Time :
10-15 daysWeight :
1500KGWanbang's turnkey modular labour camp accommodation is built for EPC contractors, construction and infrastructure projects that need to house a large workforce on a remote or restricted site. Each standard module measures 6055 × 2400 × 2896 mm and can be configured as single- or multi-room dormitory blocks, combined into two-storey arrays, and linked with ablution, kitchen, dining, office and recreation units to form a complete camp.
Request a Camp Quotation
We support layout planning, module configuration, material selection, production, shipping and on-site installation guidance so the camp can be delivered as one coordinated package. Modules are flat-pack shipped to reduce freight volume and assembled on site with bolted frames and pre-fitted services.
Final climate specifications are confirmed against project drawings and local authority requirements.
Modules are flat-pack shipped to reduce freight volume and loaded by standard container or flat-rack depending on the order. On site, each unit is lifted into place by crane and connected with bolted frames and pre-fitted services, allowing rapid camp build-out. Exact packing quantity per 40HQ, required lifting points, foundation type, labour count and installation duration must be verified with our engineering team against the confirmed layout before quotation.
A labour camp is more than dormitories. The same flat-pack system connects accommodation with site offices, meeting and welfare rooms, ablution blocks, kitchens, dining halls, laundries, clinics, security cabins, warehouses and recreation buildings.
All units share the same frame, wall and service interfaces, so a camp can be expanded or reconfigured as the workforce grows or the project phase changes.
For each project we can provide shop drawings, material specifications (BOM), factory inspection records, packing lists and installation manuals. Quality management is carried out under an ISO 9001 system, and material or product certificates are supplied according to the agreed specification.
We do not claim generic global certifications—documentation is matched to the actual configuration and destination-market requirements.
Requirement confirmation → camp layout design → quotation → shop drawing approval → production → factory inspection → shipping → on-site installation support. Our team stays involved from layout planning through to installation guidance so the delivered camp matches the approved drawings and the project schedule.
| No. | Item | Description | Size | QTY | Unit | Remark |
|---|---|---|---|---|---|---|
| — | Standard Size | 6055mm×2400mm×2896mm | 1 | set | ||
| includes | Color option | Grayish white / ivory | ||||
| 1 | Frame | Top frame | 6000mm×2400mm×160mm, 2.0mm thickness, 160mm high galvanized main beam, C90×30×1.6mm galvanized secondary beam, 20×20 square tube | 1 | set | Main beam and column made of customized high-strength galvanized coils, galvanized layer 100g/㎡ |
| Bottom frame | 6000mm×2400mm×140mm, 2.0mm thickness 140mm high galvanized main beam, C100×50×1.8mm galvanized secondary beam, L4 galvanized angle iron | 1 | set | |||
| Steel column | 150mm×150mm×2535mm, 2.0mm thick galvanized column | 4 | pcs | |||
| Surface | Plastic powder baking varnish | 1 | set | Paint film adhesion rated level 1 | ||
| 2 | Roof | Color steel tile | 0.5mm, grayish white, workshop bite type | 1 | set | |
| Glass wool + moisture-proof film | 100mm thickness, volumetric weight 24kg/m³ | 1 | set | Combustion performance A1 non-combustible | ||
| Color steel ceiling (193×2850) | 0.5mm thickness, profile machine drawing forming, invisible nail | 1 | set | |||
| 3 | Floor | Cement fibrillate plate | 18mm | 1 | set | |
| PVC floorslab | 1.8mm | 1 | set | |||
| 4 | Wall | Glass wool color steel composite sandwich panel | 0.376mm outer color steel plate with orange peel, inner 0.326mm color steel plate / 50mm thickness / 50kg glass wool, outer white gray or ivory white, inner white gray, size 1150mm×2535mm | 15 | pcs | Outer orange peel, inner plate |
| 5 | Window | Top-hung window | 900mm×500mm | 1 | set | |
| Shutters | 1150mm×440mm | 1 | set | |||
| 6 | Door | Steel door, anti-theft lock | 840mm×2035mm | 1 | set | Right hand inward |
| 7 | Electrical System | Concealed electric box | 7–9 bits | 1 | set | |
| Leakage protection switch, air switch | 32A, 16A | |||||
| Industrial plug socket | Voltage 220V, 50Hz, 3 poles, 32A | 1 | set | |||
| LED light | Light wire 2×1.5 mm², 36W | 2 | set | |||
| Exhaust fan | 300mm×300mm | 1 | set | |||
| Socket (wall) | Socket line 3×2.5 mm², 10A five holes | 4 | set | |||
| Light switch | 1 | set | ||||
| 8 | Indoor edge | PVC angle line | Top and column packages white, skirting brown | 1 | set | |
| 9 | Drain | Flashing tank, gray | 2695mm / 5695mm | 1 | set | |
| PVC drain pipe | 2720mm length × 50mm | 4 | pcs |
We have done many projects in China and overseas markets.
At least 1 unit.
Around 7-15 days after receive the deposit.
Yes, we can customize the products depending on your layout.
Our payment method usually T/T 50% deposit, and the balance 50% paid before shipment.
Send us your workforce count, site layout and destination, and we will return a camp configuration, specification sheet and quote.
